| Model |
 PowerWall 51100-S |
 PowerWall 51184-S |
|---|---|---|
| Cell Type | LiFePO4 (LFP) | |
| Battery Capacity | 100 Ah | 184 Ah |
| Nominal Battery Energy | 5.12 kWh | 9.42 kWh |
| Nominal Voltage | 51.2 V | |
| Working Voltage | 40 ~ 58.4 V | |
| Net Weight | 45 Kg | 80 Kg |
| Dimension [L*W*H] | 532 x 425 x 170 mm (20.94 x 16.73 x 6.69 in) |
535 x 720 x 176.8 mm (21 x 28.34 x 6.96 in) |
| Charging Temp. Range | 0℃ ~ 55℃ | |
| Discharging Temp. Range | -20℃ ~ 60℃ | |
| Communication | CAN/RS485 | |
| Design Life | 20 Years | |
| Warranty Document Supplied | Yes | |
| Cycle Life (25℃@80% DOD) | 6000 Cycles | |
| IP Grade | IP21 (Indoor Application / Upgrade is Available) |
|
| Scalability | Up to 16 Units in Parallel | |
| Color | Black & Gray (Customized Color is Available) |
|
| Alarms | Overcharge / Over Discharge / Overcurrent / Over Temperature / Short Circuit | |
| Monitoring & Protection | Each System has Smart BMS, Breaker Embedded in System. | |
| Pros | Can be used in both Off-Grid and Hybrid setups, compact design, floor or wall mount. | |
| Compatible Inverters | Victron / SMA / Goodwe / SRNE / Solis / SAJ / Growatt / Luxpower / Voltronic / Deye / etc. | |
| Certification & Safety Standard |
   IEC62619 / CE / UN38.3 |
|
